Qiuerte Twin-Mast Aluminum Alloy Electric Scissor Lift | High-Altitude Overnight Work Platform
Premium Performance for Elevated Efficiency
Qiuerte’s Twin-Mast Aluminum Alloy Electric Scissor Lift redefines aerial work with its robust design, advanced safety features, and unmatched versatility. Engineered for construction, maintenance, and industrial applications, this platform delivers precision and reliability at heights up to 14 meters.
Key Features
✅ Heavy-Duty Load Capacity: Supports 150kg to 300kg, ideal for tools, equipment, and multiple operators.
✅ Quick-Locking Mechanism: Effortlessly secure the platform in seconds for rapid setup and adjustments.
✅ Emergency Descent Valve: Guarantees safe, controlled lowering during power outages or emergencies.
✅ Wireless Remote Control: Operate smoothly from a distance for enhanced convenience and safety.
✅ Non-Marking Tires: Protect indoor floors and delicate surfaces while ensuring quiet mobility.
✅ Adjustable Heights: Choose from 6m, 8m, 10m, 12m, or 14m maximum lifting heights to match your project needs.
Technical Specifications
- Material: Aerospace-grade aluminum alloy (lightweight & corrosion-resistant).
- Power: Efficient electric drive system (low noise, zero emissions).
- Platform Size: Customizable non-slip deck (standard: 1.8m x 0.8m).
- Max Working Height: 6m / 8m / 10m / 12m / 14m (select during order).
- Foldable Design: Compact storage and easy transport.
Color | Customizable |
Product Features | Hydraulic |
Craft | Hydraulic |
Materials | Manganese steel, aluminium alloy, etc. |
Application | Factory, industry, warehousing, aviation, airport, port, station, gas station, stadium, etc. |
Aertification | ISO、CE、SGS、TUV |
OEM | Accept |
Product Name | Model | Platform Size(mm) | Load capacity(KG) | Max scending height(M) | Dimensions(MM) | Self weight(KG) |
Single mast | QETWY4-150-1 | 650*650 | 150 | 4 | 1420*780*1970 | 280 |
QETWY4-100-1mn | 640*490 | 100 | 4 | 1450*600*1630 | 280 | |
QETWY6-150-1 | 650*650 | 150 | 6 | 1400*780*1970 | 360 | |
QETWY6-100-1mn | 650*650 | 100 | 6 | 1450*600*1630 | 360 | |
QETWY8-130-1 | 650*650 | 130 | 8 | 1420*780*1970 | 380 | |
QETWY10-130-1 | 650*650 | 130 | 10 | 1420*780*1970 | 420 | |
Double mast | QETWY6-300-2 | 1200*630 | 300 | 6 | 1550*850*2000 | 510 |
QETWY8-300-2 | 1200*630 | 300 | 8 | 1550*850*2000 | 550 | |
QETWY10-250-2 | 1500*630 | 250 | 10 | 1840*850*2000 | 690 | |
QETWY12-200-2 | 1500*630 | 200 | 12 | 1840*850*2000 | 730 | |
QETWY14-150-2 | 1500*630 | 150 | 14 | 1950*1050*2390 | 790 | |
Three masts | QETWY12-200-3 | 1570*900 | 200 | 12 | 1900*1100*1980 | 1050 |
QETWY14-200-3 | 1570*900 | 200 | 14 | 1900*1200*2300 | 1120 | |
QETWY16-200-3 | 1570*900 | 200 | 16 | 2000*1200*2700 | 1200 | |
Four masts | QETWY12-200-4 | 1570*900 | 200 | 12 | 1900*1200*2000 | 1050 |
QETWY14-200-4 | 1570*900 | 200 | 14 | 1900*1200*2300 | 1150 | |
QETWY16-200-4 | 1570*900 | 200 | 16 | 1900*1200*2700 | 1250 | |
QETWY18-200-4 | 1570*900 | 200 | 18 | 2000*1400*2960 | 1480 |
Why Choose Qiuerte?
- Durability: Reinforced twin-mast structure ensures stability even at full extension.
- All-Day Productivity: Extended battery life supports 8+ hours of continuous operation.
- Global Compliance: CE, ISO certified, and built to international safety standards.
- Custom Solutions: Optional accessories (outriggers, LED lights, weatherproof covers).
Ideal For
- Warehouse inventory management
- Building façade repairs
- HVAC installation
- Event stage setup
- Retail shelf maintenance
Certified Safety, Uncompromised Quality
Every Qiuerte lift undergoes rigorous load-testing and includes a 1-year warranty for worry-free investment.
Ready to Elevate Your Operations?
Contact our team today for bulk discounts and OEM/ODM services:
📧 Email: market@qiuerte.com
📞 WhatsApp: +86 15290863022
Qiuerte – Engineering Heights, Delivering Trust.
NOTE:
Before we use it, we must put out the four outriggers.
And it must be used on the level ground.
It has bottom control and remote control, we can also customize a top control for you.
And this is the emergency stop button, when your press it, the lift will stop immediately.
This is the emergency relief valve, when power off or the control fails, you can use it to lower the platform.
